Productionizing MCP Part 1: Architecture & Design

Dean Jain

Senior Staff Software Engineer · Enterprise AI, Data & Cloud Architect

June 28, 2026 · 7 min read

MCPAgentic AIArchitectureSecurityObservability

Part 1 of 2. The mental model, DDD-aligned MCP architecture, and intent-shaped tool design for production MCP Understanding MCP with REST analogy

📚 Two-part series. You’re reading Part 1 Architecture & Design (the mental model, server topology, tool design with REST analogy). Part 2 Security, Observability & Governance → covers semantic-attack defense, identity & token handling, observability, governance, and testing.

TL;DR

MCP gives you a protocol, not a platform. Everything between localhost and production is the same gap we spent 15 years closing for REST and most of those lessons port directly.
A tool call is an RPC where the caller is a non-deterministic LLM that consumes untrusted text and can be steered by it. That single fact reshapes every cross-cutting concern downstream.
The architecture answer is not “monolith vs microservice.” It’s DDD-aligned, single-purpose servers behind a gateway + registry. Carve servers by bounded context, expose task-shaped tools, federate centrally.
Stop 1:1 wrapping CRUD endpoints. Design coarse, intent-based tools. Treat tool descriptions and JSON schemas as binding contracts the model reasons over and as adversarial prompt surface.
Design for statelessness now. The old spec pins clients to a session/instance; the newer spec makes requests self-contained so any instance can serve any call. Build as if you’re already there and horizontal scaling is free.
~70% of production MCP is API engineering you already know; ~30% is genuinely new. This part maps both halves. The new 30% semantic attacks, descriptions-as-behavior, token-cost SLOs, and evals as a release gate is covered in Part 2 →.

---
config:
  theme: dark
  fontSize: 17
  themeVariables:
    fontFamily: "Comic Sans MS, Comic Neue, Chalkboard SE, cursive"
---
flowchart LR
    START(["You already ship REST at scale"]):::good --> OWN["≈70% of production MCP<br/>is yours already"]:::good
    START --> GAP["≈30% is genuinely new"]:::warn
    GAP --> N1["Semantic attacks"]:::danger
    GAP --> N2["Descriptions are behavior"]:::gate
    GAP --> N3["Token cost as an SLO"]:::obs
    GAP --> N4["Evals as a release gate"]:::server
    classDef good fill:#BFEFC8,stroke:#3FA34D,stroke-width:2px,color:#0F172A
    classDef warn fill:#FFE6A8,stroke:#E0A106,stroke-width:2px,color:#0F172A
    classDef danger fill:#FFB3B3,stroke:#D14545,stroke-width:2px,color:#0F172A
    classDef gate fill:#D7C3F2,stroke:#8E5BD0,stroke-width:2px,color:#0F172A
    classDef obs fill:#AED6F1,stroke:#2E86C1,stroke-width:2px,color:#0F172A
    classDef server fill:#A8E6D0,stroke:#2FA37C,stroke-width:2px,color:#0F172A

Figure 1: REST vs MCP: ~70% of production work transfers, ~30% is genuinely new.

Spend your attention on the 30%. The rest of this article is a map of both halves.

1. The mental model: a tool call is an RPC where the caller is an LLM

MCP is, fairly, “HTTP for agents.” It standardizes how a host/client discovers and invokes capabilities on a server over JSON-RPC. The transport, the primitives, the auth handshake all of it rhymes with the API world.

The one fact that reshapes every cross-cutting concern:

The end caller is a non-deterministic model that consumes untrusted text (documents, web pages, prior tool outputs) and can be steered by it into making tool calls the user never intended.

---
config:
  theme: dark
  fontSize: 17
  themeVariables:
    fontFamily: "Comic Sans MS, Comic Neue, Chalkboard SE, cursive"
---
flowchart TB
    subgraph A["🧱 REST world deterministic"]
        direction LR
        C1["Client code"]:::neutral -->|"known request"| E1["Endpoint"]:::good
    end
    subgraph B["🤖 MCP world non-deterministic"]
        direction LR
        U2["Untrusted text:<br/>docs · web · prior output"]:::danger -.->|"can steer"| M2["LLM caller"]:::agent
        M2 -->|"inferred intent"| T2["Tool"]:::server
    end
    classDef neutral fill:#ECECEC,stroke:#8A8A8A,stroke-width:2px,color:#0F172A
    classDef good fill:#BFEFC8,stroke:#3FA34D,stroke-width:2px,color:#0F172A
    classDef danger fill:#FFB3B3,stroke:#D14545,stroke-width:2px,color:#0F172A
    classDef agent fill:#FFE08A,stroke:#E8A33D,stroke-width:2px,color:#0F172A
    classDef server fill:#A8E6D0,stroke:#2FA37C,stroke-width:2px,color:#0F172A

Figure 2: A tool call is an RPC where the caller is a non-deterministic LLM.

Concern	REST world	MCP world	What actually changes
Caller	Deterministic client code	Non-deterministic LLM	Call patterns are unpredictable; intent is inferred, not coded
Input trust	Validate the request	Validate the request and treat tool descriptions/outputs as adversarial prompt surface	New injection vectors inside “metadata”
AuthZ	User/service identity → RBAC	Same, plus “did the model decide this, or did a poisoned doc decide it?”	Audit gains an origin dimension
Rate limiting	Requests/sec	Requests/sec and token spend	Cost becomes a first-class SLO
Testing	Contract + integration	Same, plus evals (does the agent select the tool correctly?)	Descriptions are behavior, not docs

---
config:
  theme: dark
  fontSize: 17
  themeVariables:
    fontFamily: "Comic Sans MS, Comic Neue, Chalkboard SE, cursive"
---
flowchart LR
    TOOL["🔧 Tool"]:::server -->|"≈"| POST["POST endpoint /<br/>RPC method (side-effecting)"]:::neutral
    RES["📄 Resource"]:::obs -->|"≈"| GET["GET / read model"]:::neutral
    PR["💬 Prompt"]:::good -->|"≈"| TPL["Server-supplied template /<br/>stored procedure"]:::neutral
    classDef server fill:#A8E6D0,stroke:#2FA37C,stroke-width:2px,color:#0F172A
    classDef obs fill:#AED6F1,stroke:#2E86C1,stroke-width:2px,color:#0F172A
    classDef good fill:#BFEFC8,stroke:#3FA34D,stroke-width:2px,color:#0F172A
    classDef gate fill:#D7C3F2,stroke:#8E5BD0,stroke-width:2px,color:#0F172A
    classDef neutral fill:#ECECEC,stroke:#8A8A8A,stroke-width:2px,color:#0F172A

Figure 3: MCP primitives mapped to familiar API concepts.

Transports (know which era you’re in)

---
config:
  theme: dark
  fontSize: 17
  themeVariables:
    fontFamily: "Comic Sans MS, Comic Neue, Chalkboard SE, cursive"
---
timeline
    title 🚌 MCP Transport Evolution
    Nov 2024 : stdio (local only)
    Original remote : HTTP + SSE : now legacy / deprecated
    Mar 2025 : Streamable HTTP : remote, but session-pinned
    Nov 2025 : 2025-11-25 stable
    Jul 2026 (RC) : Stateless Streamable HTTP : any instance serves any call

Figure 4: MCP transport evolution: stdio to Streamable HTTP to stateless.

Design implication: the 2026-07-28 work removes the mandatory initialize handshake + Mcp-Session-Id pinning in favor of self-describing requests. That turns MCP scaling into ordinary stateless-HTTP scaling no sticky sessions, trivial autoscaling and rollout. Even on today’s spec, keep your server logic stateless so you inherit this for free.

---
config:
  theme: dark
  fontSize: 17
  themeVariables:
    fontFamily: "Comic Sans MS, Comic Neue, Chalkboard SE, cursive"
---
flowchart TB
    subgraph SF["😖 Stateful (2025-11-25) sticky sessions"]
        direction TB
        CA["Client A"]:::agent -->|"Mcp-Session-Id pins to instance"| LB1["Load balancer<br/>needs session affinity"]:::warn
        LB1 --> I1["Instance 1"]:::server
        LB1 -.->|"can't reroute"| I2["Instance 2"]:::neutral
    end
    subgraph SL["😎 Stateless (2026-07-28) any instance"]
        direction TB
        CB["Client B"]:::agent -->|"self-contained request"| LB2["Load balancer<br/>plain round-robin"]:::good
        LB2 --> J1["Instance 1"]:::server
        LB2 --> J2["Instance 2"]:::server
        LB2 --> J3["Instance 3"]:::server
    end
    classDef agent fill:#FFE08A,stroke:#E8A33D,stroke-width:2px,color:#0F172A
    classDef server fill:#A8E6D0,stroke:#2FA37C,stroke-width:2px,color:#0F172A
    classDef warn fill:#FFE6A8,stroke:#E0A106,stroke-width:2px,color:#0F172A
    classDef good fill:#BFEFC8,stroke:#3FA34D,stroke-width:2px,color:#0F172A
    classDef neutral fill:#ECECEC,stroke:#8A8A8A,stroke-width:2px,color:#0F172A

Figure 5: Stateful (session-pinned) vs stateless horizontal scaling.

2. Architecture: stop asking “monolith or microservice”

That’s the wrong axis. The right question is the one DDD already answered for services: where are the bounded contexts, and who owns them?

The two failure modes at the extremes

One mega-server (“the MCP monolith”)

---
config:
  theme: dark
  fontSize: 17
  themeVariables:
    fontFamily: "Comic Sans MS, Comic Neue, Chalkboard SE, cursive"
---
flowchart TB
    MEGA["🗿 One mega-server<br/>(60+ tools)"]:::danger
    MEGA --> X1["❌ Tool explosion<br/>model picks wrong, tokens burn"]:::warn
    MEGA --> X2["❌ Blast radius<br/>one bug kills everything"]:::warn
    MEGA --> X3["❌ Ownership smear<br/>5 teams, 1 repo"]:::warn
    MEGA --> X4["❌ Deploy coupling<br/>Slack waits on Billing"]:::warn
    classDef danger fill:#FFB3B3,stroke:#D14545,stroke-width:2px,color:#0F172A
    classDef warn fill:#FFE6A8,stroke:#E0A106,stroke-width:2px,color:#0F172A

Figure 6: The MCP monolith failure mode.

Fifty servers wired directly into every client (“the N×M mess”)

---
config:
  theme: dark
  fontSize: 17
  themeVariables:
    fontFamily: "Comic Sans MS, Comic Neue, Chalkboard SE, cursive"
    lineColor: "#C0504D"
---
flowchart LR
    A1["Client 1"]:::agent --> S1["Server A"]:::server
    A1 --> S2["Server B"]:::server
    A1 --> S3["Server C"]:::server
    A2["Client 2"]:::agent --> S1
    A2 --> S2
    A2 --> S3
    A3["Client 3"]:::agent --> S1
    A3 --> S2
    A3 --> S3
    NOTE["⚠️ N×M wiring · config sprawl ·<br/>no central policy or discovery"]:::danger
    classDef agent fill:#FFE08A,stroke:#E8A33D,stroke-width:2px,color:#0F172A
    classDef server fill:#A8E6D0,stroke:#2FA37C,stroke-width:2px,color:#0F172A
    classDef danger fill:#FFB3B3,stroke:#D14545,stroke-width:2px,color:#0F172A

Figure 7: The N x M direct-wiring mess.

The synthesis: DDD servers + a gateway + a registry

This is the pattern converging across the ecosystem (variously “Macro-MCP,” “MCP gateway,” “virtual MCP servers”):

---
config:
  theme: dark
  fontSize: 17
  themeVariables:
    fontFamily: "Comic Sans MS, Comic Neue, Chalkboard SE, cursive"
---
flowchart TB
    A1["🤖 Agent / Host A"]:::agent
    A2["🤖 Agent / Host B"]:::agent
    A3["🤖 Agent / Host C"]:::agent
    GW["🛡️ MCP GATEWAY single virtual endpoint<br/>authN/Z · routing · policy<br/>rate + cost limits · audit · OTel"]:::gate
    S1["⚙️ personal-assistant MCP server"]:::server
    S2["⚙️ Benefits MCP server"]:::server
    S3["⚙️ Search MCP server"]:::server
    D1[("🗄️ Core DB")]:::down
    D2["☁️ SaaS API"]:::down
    D3["🏢 Internal API"]:::down
    REG["📚 REGISTRY discovery + governance<br/>central IT ⇄ LOB (federated)"]:::gov
    A1 --> GW
    A2 --> GW
    A3 --> GW
    GW --> S1
    GW --> S2
    GW --> S3
    S1 -->|"token exchange (RFC 8693)"| D1
    S2 --> D2
    S3 --> D3
    REG -.->|"feeds approved tools"| GW
    classDef agent fill:#FFE08A,stroke:#E8A33D,stroke-width:2px,color:#0F172A
    classDef gate fill:#D7C3F2,stroke:#8E5BD0,stroke-width:2px,color:#0F172A
    classDef server fill:#A8E6D0,stroke:#2FA37C,stroke-width:2px,color:#0F172A
    classDef down fill:#FFC2B4,stroke:#E8694A,stroke-width:2px,color:#0F172A
    classDef gov fill:#E0D6F5,stroke:#9B7EDE,stroke-width:2px,color:#0F172A

Figure 8: Reference architecture: agents to gateway to servers to downstream, plus registry.

Layer	Responsibility	REST analog
Single-purpose server	One bounded context’s tools; team-owned; independently deployable/scalable	A domain microservice
Gateway	Single endpoint; centralizes authN/Z, routing, rate/cost limits, audit, telemetry, allowlists; can fan-out and merge tool lists into a virtual server	API gateway (Kong/Apigee/Envoy)
Registry	Discovery + governance: which servers exist, who approved them, which agents see which tools	API catalog / developer portal

A single well-scoped server fronted by your existing API gateway is a perfectly good starting point. Don’t build the control plane before you have the servers to control. But design each server so it can slot behind a gateway later (stateless, pure RS, OTel-instrumented).

Frameworks (architecture/runtime)

Clients / Orchestrators: LangChain and LlamaIndex (which act as the client calling your MCP servers).
Servers: official SDKs (TypeScript, Python, Go, Java); FastMCP (Python) for ergonomics.
Gateways: GCP API Gateway, Cloudflare Workers MCP, AWS MCP Gateway & Registry.
Pick a gateway when: heterogeneous teams, centralized policy/audit, or aggregating many servers. Roll your own thin proxy when: one or two servers and an existing gateway you can extend.

3. Domain design: carving servers and shaping tools

The discipline is the same as service design; the new wrinkles are that the model reads your descriptions and the model picks your tools.

---
config:
  theme: dark
  fontSize: 17
  themeVariables:
    fontFamily: "Comic Sans MS, Comic Neue, Chalkboard SE, cursive"
---
flowchart TD
    BC["🗂️ Bounded context (domain)"]:::gov --> SRV["⚙️ One MCP server (team-owned)"]:::server
    SRV --> T1["🔧 Tool: capability A"]:::agent
    SRV --> T2["🔧 Tool: capability B"]:::agent
    SRV --> R1["📄 Resource: read model"]:::obs
    SRV --> P1["💬 Prompt: shared template"]:::good
    classDef gov fill:#E0D6F5,stroke:#9B7EDE,stroke-width:2px,color:#0F172A
    classDef server fill:#A8E6D0,stroke:#2FA37C,stroke-width:2px,color:#0F172A
    classDef agent fill:#FFE08A,stroke:#E8A33D,stroke-width:2px,color:#0F172A
    classDef obs fill:#AED6F1,stroke:#2E86C1,stroke-width:2px,color:#0F172A
    classDef good fill:#BFEFC8,stroke:#3FA34D,stroke-width:2px,color:#0F172A

Figure 9: DDD: bounded context to one server to tools, resources, prompts.

Tool granularity: design for intent, not CRUD

The single most common anti-pattern is 1:1 wrapping every REST endpoint as a tool. It re-creates tool explosion and forces the model to orchestrate low-level calls it will get wrong.

---
config:
  theme: dark
  fontSize: 17
  themeVariables:
    fontFamily: "Comic Sans MS, Comic Neue, Chalkboard SE, cursive"
---
flowchart TB
    subgraph BAD["❌ 1:1 CRUD wrapping model must chain 4 calls"]
        direction LR
        m1["🤖 LLM"]:::agent --> g1["getCustomer"]:::danger --> g2["getCustomerOrders"]:::danger --> g3["getOrderItems"]:::danger --> g4["getItemDetails"]:::danger
    end
    subgraph GOOD["✅ Task-shaped tool one intent, server orchestrates"]
        direction LR
        m2["🤖 LLM"]:::agent --> t1["get_customer_order_history(id)"]:::good
    end
    classDef agent fill:#FFE08A,stroke:#E8A33D,stroke-width:2px,color:#0F172A
    classDef danger fill:#FFB3B3,stroke:#D14545,stroke-width:2px,color:#0F172A
    classDef good fill:#BFEFC8,stroke:#3FA34D,stroke-width:2px,color:#0F172A

Figure 10: 1:1 CRUD wrapping vs a single task-shaped tool.

Rule of thumb: a tool should map to a unit of user/agent intent, not a database operation. Coarser, task-oriented tools mean fewer tokens, better selection accuracy, and less room for the model to assemble something dangerous.

Descriptions are a first-class (and adversarial) interface

The description and JSON schema are the contract the model reasons over. Treat them with the rigor of an API spec and the suspicion of untrusted input (see Part 2 tool poisoning).
Be explicit about side effects, idempotency, and when not to call the tool.
Keep parameter schemas tight (types, enums, length/format) they double as input validation and model guardrails.

Versioning & change management (port the API playbook directly)

---
config:
  theme: dark
  fontSize: 17
  themeVariables:
    fontFamily: "Comic Sans MS, Comic Neue, Chalkboard SE, cursive"
---
flowchart LR
    V1["🔧 v1 tool"]:::server -->|"additive change"| V2["🔧 v2 tool<br/>backward compatible"]:::good
    V2 -->|"mark deprecated"| DEP["⏳ Deprecation window<br/>watch usage telemetry"]:::warn
    DEP -->|"usage ≈ 0"| REM["🗑️ Remove"]:::neutral
    CHG["⚠️ Silent definition change"]:::danger -.->|"= RUG PULL"| RECON["🔒 Force re-review<br/>+ re-consent"]:::gate
    classDef server fill:#A8E6D0,stroke:#2FA37C,stroke-width:2px,color:#0F172A
    classDef good fill:#BFEFC8,stroke:#3FA34D,stroke-width:2px,color:#0F172A
    classDef warn fill:#FFE6A8,stroke:#E0A106,stroke-width:2px,color:#0F172A
    classDef neutral fill:#ECECEC,stroke:#8A8A8A,stroke-width:2px,color:#0F172A
    classDef danger fill:#FFB3B3,stroke:#D14545,stroke-width:2px,color:#0F172A
    classDef gate fill:#D7C3F2,stroke:#8E5BD0,stroke-width:2px,color:#0F172A

Figure 11: Tool lifecycle, versioning, and the rug-pull risk.

Additive, backward-compatible changes by default; new tools rather than breaking signatures.
Deprecation windows with usage telemetry before removal the MCP project itself is moving to deprecation-window + extension discipline; mirror it.
Treat a changed tool definition as a contract change requiring re-review and (for clients that approved it) potential re-consent silent changes are the “rug pull” attack (covered in Part 2).

Resources vs tools

Resource when the model should read data with no side effect. Application decides what to surface.
Tool when the model should act or run a parameterized query. Side-effecting or compute-bearing.
Don’t expose mutation as a “resource,” and don’t force read-only context through tool calls.

Continue to Part 2

You now have the architecture and design foundation the mental model, where to draw server boundaries, and how to shape tools. Part 2 covers the cross-cutting concerns that decide whether MCP survives contact with production: defending semantic attacks, identity & token handling, observability with token-cost and audit-origin, governance via the registry, and testing with evals.

→ Read Part 2: Security, Observability & Governance
